Inconel 600 Round Bar
➡️ Alloy 600 | UNS N06600 | EN 2.4816
➡️ ASTM, EN, JIS & International Standards
➡️ Supply Conditions
➡️ Multiple Diameters & Supply Lengths
➡️ Global Export & International Delivery
Country of Origin:
Europe, Japan, USA
Material Type:
Nickel Alloy
UNS Number:
N06600
Wr. No.:
2.4816
MTC Available:
EN 10204 3.1
Product Description for Inconel 600 Round Bar
Inconel 600 is a nickel-chromium alloy, UNS N06600 and Werkstoff 2.4816. Material is furnished to ASTM B166, the standard covering nickel-chromium-iron alloy rod, bar and wire, with ASME SB-166 applying to pressure equipment and ASTM B564 to forgings.
The composition is nickel 72% minimum with 14-17% chromium and 6-10% iron. Nickel at that level carries the alloy’s headline property: near immunity to chloride stress corrosion cracking, the failure mode that limits austenitic stainless steels in warm chloride service. Chromium adds oxidation resistance and handles sulphur-bearing and oxidising conditions.
It also resists dry chlorine and hydrogen chloride to around 550 C, and performs well in caustic solutions including caustic soda at concentration.
The alloy is solid-solution strengthened only, with no precipitation hardening, so it cannot be heat treated to higher strength. Bar is supplied annealed or hot-finished, and strength comes from cold work where more is needed.
Oxidation resistance extends to roughly 1090 C, and the alloy retains useful strength and structural stability across the whole range from cryogenic temperatures upward.
Two limits decide where it goes. There is no molybdenum, so it is not a pitting-resistant grade and performs poorly in oxidising chloride solutions such as ferric chloride, where Alloy 625 or a Hastelloy grade is needed. And prolonged exposure between roughly 540 C and 760 C can sensitise the material through chromium carbide precipitation.
Sizes run 6 mm to 250 mm, either random or cut to length. The alloy is non-magnetic at room temperature.
Typical work is furnace and heat-treatment fixtures, chemical process hardware, nuclear steam generator components, chloride and caustic service parts, and machined fittings for high-temperature systems.
Common Applications of Inconel 600 Round Bar
➡️ Machined shafts, spindles, valve stems, pump sleeves and pins for food, beverage, dairy and pharmaceutical equipment, where the passive chromium oxide film resists both product acids and caustic clean-in-place chemicals.
➡️ Fasteners, studs, bolts, threaded rod and anchor components produced from bar stock, chosen for corrosion resistance combined with the ductility needed for cold heading and thread rolling.
➡️ Chemical, water treatment and general process plant parts such as agitator shafts, flange blanks, nozzles and support components handling water, steam and mildly corrosive media free of significant chlorides.
➡️ Architectural and structural hardware including handrail stanchions, balustrade fittings, tension rods and bollards, where a bright ground or polished bar finish provides both appearance and low maintenance.
International Equivalent Grade for Alloy 600 Round Bar
Standard
Country / Region
Grade
ASTM B166
USA
UNS N06600 (rod, bar and wire)
ASME SB-166
USA
UNS N06600
ASTM B564
USA
UNS N06600 (forgings)
EN 10095 / DIN 17742
Europe / EU
2.4816 (NiCr15Fe)
BS 3076
United Kingdom
NA 14
Technical Specification for Inconel 600 Round Bar
Specification
Value
Unit
Material
Nickel alloy
-
Grade
Inconel 600 / UNS N06600 / 2.4816
-
Product Form
Round bar / rod
-
Standard
ASTM B166, ASME SB-166
-
Diameter
6 - 250 (typical supply range)
mm
Length
3 - 6 (random), or cut to length
m
Manufacturing Process
Hot rolled or forged, annealed
-
Production Route
EAF + AOD, with VIM or ESR remelt where specified
-
Surface Finish
Hot-rolled and pickled, peeled, turned, centreless ground, polished
-
Heat Treatment / Delivery Condition
Annealed or hot-finished, as ordered
-
Tolerance Standard
ASTM B166 permissible variations
-
Density
8.47 (typical)
g/cm3
Melting Range
1354 - 1413 (typical)
C
Thermal Conductivity at 20 C
14.9 (typical)
W/m.K
Coefficient of Thermal Expansion (20-100 C)
13.3 (typical)
um/m.C
Specific Heat (0-100 C)
444 (typical)
J/kg.K
Electrical Resistivity at 20 C
1.03 (typical)
uOhm.m
Modulus of Elasticity at 20 C
207 (typical)
GPa
Magnetic Properties
Non-magnetic at room temperature
-
Maximum Service Temperature
1090 (typical, oxidising atmosphere)
C
Testing / Inspection Standard
ASTM E8 or ASTM A370 for mechanical testing
-
Certification / Inspection Documents
EN 10204 3.1 or 3.2 mill test certificate
-
Technical Specifications
Get the key technical specifications for Inconel 600 Round Bar
Order to ASTM B166 under UNS N06600, with ASME SB-166 invoked for pressure-retaining components and ASTM B564 covering forgings. Dimensional tolerance, straightness and surface condition come from the permissible variations tables within B166 itself, not from ASTM A484 or A29 which cover stainless and alloy steel respectively.
Delivery is annealed or hot-finished. The alloy is solid-solution strengthened with no precipitation hardening available, so heat treatment cannot raise strength. Cold work is the only route, and it is reversed by annealing.
Two limitations decide where the alloy is used. It has essentially no molybdenum, so it is not a pitting-resistant grade and performs poorly in oxidising chloride solutions such as ferric chloride, where Alloy 625 or a Hastelloy grade is required instead. And prolonged exposure between roughly 540 C and 760 C can sensitise the material through chromium carbide precipitation, which affects resistance to intergranular attack in wet service afterwards.
Where it excels is chloride stress corrosion cracking resistance, caustic service, dry chlorine and hydrogen chloride to around 550 C, and high-temperature oxidation.
Machining behaves like most solid-solution nickel alloys: the material work hardens rapidly, so rigid setups, sharp tooling, positive feeds and slower speeds are needed. Welding uses matching or over-alloyed nickel-base filler.
Chemical Composition for Inconel 600 Round Bar
Element
Symbol
Min
Max
Unit
Nickel
Ni
72.0
-
%
Chromium
Cr
14.00
17.00
%
Iron
Fe
6.00
10.00
%
Carbon
C
-
0.15
%
Manganese
Mn
-
1.00
%
Silicon
Si
-
0.50
%
Copper
Cu
-
0.50
%
Sulfur
S
-
0.015
%
Chemical Composition
View the chemical composition and applicable material limits for Alloy 600 Round Bar
Nickel at 72% minimum is the defining element and it is specified as a floor rather than a range, with iron and chromium making up the balance. At that level the alloy is effectively immune to chloride stress corrosion cracking, which is the mechanism that most often finishes austenitic stainless steels in warm chloride service. High nickel also gives excellent resistance in caustic solutions and provides structural stability from cryogenic temperatures right through to around 1090 C.
Chromium at 14.00-17.00% supplies oxidation resistance at high temperature and handles oxidising and sulphur-bearing conditions that attack pure nickel. It forms the protective oxide that lets the alloy work in furnace atmospheres.
Iron at 6.00-10.00% is a deliberate range rather than a residual. It reduces cost against a higher-nickel alloy while keeping the properties that matter.
Carbon is permitted to 0.15%, high by modern standards, and it is the reason prolonged exposure between roughly 540 C and 760 C can sensitise the material through chromium carbide precipitation.
Copper is capped at 0.50%, manganese at 1.00% and silicon at 0.50%. Sulphur is held tight at 0.015%, since sulphur is particularly damaging to hot workability and weldability in nickel alloys.
Note that there is no molybdenum, which is why the alloy is not pitting resistant.
Mechanical Properties for Inconel 600 Round Bar
Mechanical Property
Value
Unit
Tensile Strength, annealed
550
MPa (minimum)
Yield Strength 0.2% Proof, annealed
240
MPa (minimum)
Elongation in 50 mm, annealed
30
% (minimum)
Hardness, annealed
184
HB (maximum, ASTM B166)
Hardness, annealed
65 - 85
HRB (typical)
Modulus of Elasticity
207
GPa (typical)
Mechanical Properties
Check the key mechanical properties and performance requirements of Alloy 600 Round Bar
ASTM B166 sets these for annealed UNS N06600 bar, all minima except hardness, which ASTM B166 caps at 184 HB. Testing follows ASTM E8 or ASTM A370. Hot-finished material carries slightly different requirements from annealed, so the condition should be stated on the order.
Strength is moderate and is not the reason anyone specifies this alloy. At 550 MPa minimum tensile and 240 MPa minimum proof strength it sits close to annealed 304 stainless. What sets it apart is corrosion behaviour and the ability to hold structural stability over an exceptionally wide temperature range.
The alloy is solid-solution strengthened only. There is no precipitation-hardening response, so heat treatment cannot increase strength, and any additional strength has to come from cold work, which reduces ductility and is removed by subsequent annealing.
Ductility is high at 30% minimum elongation, and toughness remains good down to cryogenic temperatures because the structure is austenitic with no ductile-to-brittle transition.
For elevated-temperature design, creep and stress-rupture data govern rather than these room-temperature figures. Strength falls steadily above about 600 C, and the practical limit of roughly 1090 C is set by oxidation rather than by load-bearing capability.
Dimension / Sizes for Inconel 600 Round Bar
Dimension / Size
Value
Unit
Diameter
6 - 250
mm
Standard Length
3 - 6 (random / mill lengths)
m
Custom Length
Cut to length available on request
-
Diameter Tolerance
Per ASTM B166 permissible variations, varies with size and finish
-
Length Tolerance
Per ASTM B166 or as agreed at order
-
Straightness Tolerance
Per ASTM B166 or as agreed at order
-
End Condition
Square cut, chamfered, or as ordered
-
Surface Finish
Hot-rolled and pickled, peeled, turned, centreless ground, polished
-
Available Size Range
6 - 250, larger diameters by forging on enquiry
mm
Cut-to-Length Availability
Available
-
Dimensional Standard
ASTM B166
-
Dimensions & Sizes
Explore available diameters, lengths, and dimensional requirements for Alloy 600 Round Bar
Pricing for Inconel 600 Round Bar
Round Bar Prices are generally quoted per kilograms or meters tonnes and can fluctuate with the global raw material and market prices. The final price will depend on a variety of factors, including the grade size, diameter, length, surface finish, the quantity and whether the bars are cut to length or in standard lengths.
For smaller quantities, we can also quote per metre or per piece basis once the required dimensions have been confirmed. Container-loads or orders that are larger in size are typically priced per tonne, based upon the specifications required and the supply conditions.
Please provide your desired dimensions, grades, length number, and end for a current quote including the lead time applicable and details for certification.
Pricing
Get current Inconel 600 Round Bar pricing based on size, quantity, grade, finish, and delivery requirements.
Why Choose Us
Euro Steel Bars is an international distributor, stockist and exporter of stainless round steel bars that cover carbon, stainless alloy, special grades. We stock a variety of sizes and grades. We guarantee every order with mill test certificates as well as full quality-assurance documentation. Our name speaks to our roots: European-sourced materials that is backed by the certificates and rigor that buyers from Asia as well as the Gulf and Africa are looking for.
Each bar we deliver is accompanied by EN 10204 3.1 mill test certificates as well as complete documentation of quality, so what you receive corresponds to what’s written in the documents. We carry a selection of sizes and grades ready for transport, and cut length upon the request of customers, which results in quicker lead times, whether you’re ordering just a one-off spec or a complete project tonnage.
We operate an actual wholesale business that is that is supported with an internationally-operated supply chain therefore we are able to serve fabricators sourcing one grade the same way in the same way as an EPC contractor who is placing a large order. Our clients include manufacturers, fabricators EPC construction companies, engineers oil and gas projects as well as construction companies. we design our inventory as well as documentation to show what buyers need to bring projects forward.
Our customers trust us across Qatar, Oman, Bahrain, Kuwait, Jordan, Malaysia, Singapore, Thailand, Taiwan, Turkey, Italy and South Africa. If you’re looking to source an Gulf energy project, or a construction project within Southeast Asia, you get the same quality of certified material, the exact documentation, and the exact delivery procedure.
Frequently Asked Questions
What is Inconel 600 Round Bar?
What standard does Inconel 600 Round Bar comply with?
What are the equivalent grades of Inconel 600 Round Bar?
What are the key mechanical properties of Inconel 600 Round Bar?
Why does Inconel 600 resist chloride stress corrosion cracking?
When should Inconel 600 not be used?
Can Inconel 600 be hardened by heat treatment?
What sizes and lengths are available?
